LY042
Thermal imaging transfer aiming

LY042

Thermal imaging transfer aiming

The wide view and easy operation will make your outdoor life get more fun
    ● Quick conversion between attachment and monocular；
    ● Quick mounting and removal of attachment
    ● Detection range above 1.5km；
    ● 1024×768 high resolution OLED display；
    ● Bluetooth remote control；
    ● Four image modes – white hot, black hot, red hot, pseudo color;
    ● Monocular digital zoom：×1、×2、×4；
    ● Type-C interface power supply and data transmission;
    ● Build-in Bluetooth, compass, motion sensor;
    ● IP67 protection level； ● Compact size； ● Light weight and high impact resistance
Application： Personal security Search and rescue Outdoor exploration Night patrol
SERVICE & SUPPORT   |    CONTACT US

Characteristics

● Screen lightness：1~4 lightness level;
● Image mode: W (White hot), B (Black hot), R (Red hot), C (pseudo color);
● E-zoom (only for monocular): ×1、×2、×4.
Ultraclear Mode
Bluetooth;Video Output
Battery Type
Blind pixel correction
Factory reset
 You will see on the display: two measurement bars, icons of three reference objects and respective distances foe the three objects.
There are three pre-set reference objects:  Hare - height 0.2m  Wild boar - height 0.8m  Deer - height 1.7m.
Aim at the target, and then adjust the distance between the measurement bars by pressing Power button or C button until the target matches entirely between the two bars. Power button is used to increase the distance and C button to reduce the distance.

Demonstrate

Application

Specification


Model

LY042

Detector

VOx Uncooled

Resolution

384x288

Pixel Size

17um

NETD

≤50mk

Frame Rate

50Hz

Objective Lens

42mm

Field of View

8.9°×6.7°

Magnification

1×

Detection Range

(Target size：1.7m×1.2m)

Detection：2100m（2 pixels）

Recognition：700m（6 pixels）

Display

OLED

Resolution

1024×768

Battery

CR123×2

Power Consumption

＜1500mW

Max. Battery Life

4hr

USB Interface

Type-C

Video Output

PAL(RCA 接口)

External Power

Type-C

Digital Compass

√

Motion Sensor

√

Remote Control

Bluetooth

Replaceable Parts

M18 Monocular Eyepiece

IP Rating

IPX67

Weight (without batteries)

＜420g

Dimension

154mm×61mm×58mm

Adapter Ring

M52×0.75
